Stealth Bomber 2-Channel Class-D Full Range Amplifier - B52
Weight: 2.8 lb
Couldn't load pickup availability
Overview
Stealth Bomber 2-Channel Class-D Full Range Amplifier
Upgrade your car audio system with the Cerwin-Vega B52 Stealth Bomber 2-Channel Class-D Full Range Amplifier, a compact powerhouse engineered to deliver clean, dynamic sound with impressive efficiency. Part of the innovative Cerwin-Vega Stealth Bomber Series, the B52 amplifier combines advanced digital amplifier technology with a sleek, ultra-compact design that fits easily into tight installation spaces.
The Cerwin-Vega B52 2-channel amplifier features a high-efficiency full-range Class-D digital topology, providing powerful audio output while minimizing energy loss and heat generation. This advanced design ensures exceptional sound clarity, making it ideal for powering component speakers, coaxial speakers, or small subwoofer setups in modern car audio systems.
At the heart of the B52 amplifier is a Class-D IR chipset with Direct-FET Power MOSFET output stage, delivering precise signal processing and stable power performance. This technology ensures your music remains crisp, detailed, and distortion-free even at higher listening levels.
Built for durability and reliability, the Stealth Bomber B52 amplifier features an ultra-compact high-density aluminum alloy chassis that provides excellent heat dissipation and structural protection. This rugged design allows the amplifier to perform consistently in demanding automotive environments while maintaining optimal operating temperatures.
To protect your system, the B52 includes advanced rollback power and thermal protection, which safeguards the amplifier during extreme operating conditions. These built-in safety features help maintain long-term reliability and consistent audio performance.
For flexible sound customization, the amplifier includes switchable 12dB crossovers (HP/FLAT/LP), allowing you to configure the amplifier for full-range speakers or dedicated subwoofer applications. The VEGA Bass Boost feature enhances low-frequency response, adding extra punch and depth to your system.
Installation is simple thanks to the remote turn-on configurator (REM/DC/VOX), enabling seamless integration with factory or aftermarket head units.
Key Features:
• 2-channel Class-D full-range amplifier
• High-efficiency digital amplifier topology
• Direct-FET Power MOSFET output stage
• Ultra-compact aluminum alloy chassis
• 12dB switchable HP/FLAT/LP crossovers
• VEGA Bass Boost for enhanced low-end response
• Advanced power and thermal protection
The Cerwin-Vega B52 Stealth Bomber Amplifier delivers powerful performance, installation flexibility, and legendary Cerwin-Vega sound, making it the perfect solution for high-performance car audio speaker systems.
Specifications
POWER RATING
FREQUENCY RESPONSE (HZ): 70HZ-20KHZ
RMS POWER PER CHANNEL 4Ω 150W X 2
RMS POWER PER CHANNEL 2Ω 250W X 2
RMS POWER PER 2 CHANNELS BRIDGED 4Ω 500W X 1
POWER SUPPLY
- Power Supply: Full PWM
- Power Supply Threshold: 10.0V-17.0V (DC)
- Idle Current: (0.7A)
DISTORTION
- THD 4 (1KHz @4Ω): 0.05%
- S/N Ratio (A weighted @1W): -85 dBA
- S/N Ratio (A weighted @FP): -101.1 dBA
INPUT SENSITIVITY
- Low Input Level: 200mV-10.0V
- High Input Level: 200mV-10.0V
INPUT IMPEDANCE
- Low Input Level: 20 KΩ
- High Input Level: 20 KΩ
OUTPUT STAGE
- Output Impedance: 0.011Ω
- Damping Factor (50Hz @ 4Ω): >250
- Bandwidth (-3dB): 10Hz-35KHz
CROSSOVER (-12/-24 dB/Oct)
- Variable High-Pass:
- Variable Low-Pass: 40Hz-400Hz
- Variable Sub-Sonic: 10Hz-55Hz
FUSE RATINGS
- ATC: 25A
DIMENSIONS
- L x W x H: 7.7”x 4.02”x 1.4” (195.6mm x 102mm x 36mm)
FEATURES
- Full Range Class D IR Chipset
- DirectFET Power Mosfet Output Stage
- SMD Technology on 4-Layer PCB Board
- Water Resistant Conformal PCB Board Coating
- 1-year Manufacturer's Warranty
- MFR #: B52
Product Manuals

Stealth Bomber series amplifiers have been the cornerstone of the Cerwin-Vega Mobile brand
Embodying power, precision, and reliability for car audio enthusiasts.
Don't be fooled by the sleek and compact design of Stealth Bomber series amplifiers
They ensure seamless installation while delivering monstrous power output.
Lots of ground loop noise with this little guy. Was so disappointed that I had to return it.
Not sure how or why but even though I had multiple fuses to protect the amp it blew a fuse then blew the speakers. I would buy again though but im insane i guess.
It’s great for 6 1/2in speakers nice clean sounds good clean Resonance through full spectrum of sound through a set of nice speakers. not low end sounds. It will not push a sub for your life. all the interior speakers will out do the sub for low end. If you want bass get a different amp
The is the worse amp I ever brought. DO NOT buy. It keeps cutting on & off. Due to Covid I just recently had it professional installed and it’s crap.
Great product!
