1-Channel XED Series Monoblock Class-D Amplifier - XED3001D
Couldn't load pickup availability
Secure Checkout
100% Authentic
Free Shipping
Live Support
Overview
1 Channel XED Series Monoblock Class-D Amplifier
Upgrade your car audio system with the Cerwin-Vega XED3001D XED Series 1-Channel Monoblock Class-D Amplifier, a compact yet powerful amplifier designed to deliver deep, impactful bass and efficient power performance. Built using Cerwin-Vega’s advanced Xtreme Energy Design, the XED3001D provides the ideal combination of reliability, efficiency, and strong low-frequency output for modern car audio systems.
The XED3001D monoblock amplifier is specifically engineered to power subwoofers, delivering focused power that maximizes bass performance while maintaining clean, distortion-free sound. Whether you're upgrading a factory audio system or building a custom aftermarket setup, this amplifier provides the power needed to drive your subwoofer with authority and precision.
Featuring advanced Class-D amplifier technology, the XED3001D offers high efficiency and powerful output while generating minimal heat. This modern amplifier design allows it to deliver strong bass performance without placing excessive demand on your vehicle’s electrical system. The result is consistent, reliable sound quality even during extended listening sessions.
The amplifier is housed in a lightweight aluminum chassis that not only enhances durability but also acts as an effective heat sink to help dissipate heat and maintain optimal operating temperatures. This rugged construction ensures dependable long-term performance while keeping the amplifier compact for flexible installation in a wide variety of vehicles.
Engineered with premium internal components and precision construction, the Cerwin-Vega XED Series amplifiers are designed to handle demanding audio systems with ease. The XED3001D delivers tight bass response, clean signal reproduction, and the dynamic energy that Cerwin-Vega is known for.
Key Features:
• 1-channel monoblock Class-D car audio amplifier
• Designed specifically for high-performance subwoofer systems
• High-efficiency amplifier technology for powerful output
• Lightweight aluminum chassis for superior heat dissipation
• Clean, distortion-free bass reproduction
• Ideal for aftermarket subwoofer upgrades
The Cerwin-Vega XED3001D amplifier delivers the powerful bass performance and efficiency needed to bring your music to life—unleashing the Xtreme Energy and legendary Cerwin-Vega sound on every drive.
Specifications
XED Series 1-Channel Mono Block Amplifier
Power Rating (RMS)
FREQUENCY RESPONSE (HZ): 35HZ - 350HZ
RMS POWER PER CHANNEL 4Ω 200W X 1
RMS POWER PER CHANNEL 2Ω 300W X 1
Power Supply
- Power Supply: Full WPM
- Power Supply Threshold: 10.0V-16.0V (DC)
- Idle Current: (0.7A)
Distortion
- THD 4 (100HZ @4Ω): 0.1%
- S/N RATIO (A WEIGHTED @1W): -85dBA
- S/N RATIO (A WEIGHTED @FP): -101.1dBA
Input Sensitivity
- Low Level Input: 250mV-6.0V
- High Level Input: 1.1V~>20.0V
Input Impedance
- Low Level Input: 20KΩ
- High Level Input: 100KΩ
Output Stage
- Output Impedance: 2Ω
- Damping Factor (50Hz@4Ω): >70
- Bandwidth (-3db): 10Hz-250Hz
Crossover (1-12dB/Oct)
- Variable High-Pass:
- Variable low-Pass: 35Hz-250Hz
Fuse Rating
- ATC: 20A x 2 (Inside)
Dimensions
- Length x Width x Height: 6.3”x4.7”x1.8” (160mm x 120mm x 46.5mm)
FEATURES
- Bass Boost: 0dB-12dB
- LED Power/Protect Light Indicator
- Bass Control Included
Product Manuals

Xtreme Power, Ultimate Precision
The XED3001D 1-Channel Class-D Amplifier delivers high-efficiency power and clean sound. With advanced Class D technology and a lightweight aluminum chassis, it ensures reliable performance while driving subwoofers and speakers with ease.
Built for High-Performance Systems
Crafted with premium components and robust construction, the XED3001D handles demanding setups effortlessly. Experience deep bass, crisp highs, and seamless mids for an immersive car audio experience.
