VMAXX Series 10" Shallow Dual Voice Coil Subwoofer (2Ω) - VMAXS102
Weight: 11.58 lb
Couldn't load pickup availability
Overview
VMAXS102 – 10” VMAXX Series DVC Shallow Subwoofer (2Ω)
Get powerful bass in tight spaces with the Cerwin-Vega VMAXS102 10-inch DVC shallow subwoofer, engineered for high-performance audio systems where space is limited but output matters. Designed as part of the VMAXX Series, this 10” 2-ohm dual voice coil subwoofer delivers strong, clean bass without requiring a large enclosure.
With a 300W RMS / 600W MAX power rating, the VMAXS102 provides impressive low-frequency performance for compact installations. Its dual 2-ohm voice coil configuration offers flexible wiring options, allowing you to optimize impedance and maximize amplifier efficiency. Whether installed under a seat or in a shallow enclosure, this subwoofer is built to perform.
The VMAXS102 features a 2.5-inch high-temperature voice coil and a high-excursion design, enabling greater cone movement for deeper bass and improved low-frequency response. Despite its shallow profile, it produces tight, punchy bass with excellent clarity and minimal distortion, making it ideal for a wide range of music styles.
Engineered for durability, this Cerwin-Vega shallow mount subwoofer is constructed with high-quality materials and a robust motor structure, ensuring long-lasting reliability even under demanding conditions. Its compact dimensions, including a 3.11” mounting depth and 9.47” mounting diameter, make it perfect for vehicles with limited installation space.
The VMAXS102 is ideal for those looking for a shallow mount subwoofer, compact 10-inch subwoofer, or space-saving bass solution without sacrificing performance. It works well in sealed or shallow vented enclosures, giving you flexibility to tailor your sound.
Upgrade your system with the Cerwin-Vega VMAXS102—compact design, powerful output, and legendary bass performance built to fit where others can’t.
Specifications
SPEAKER SIZE - 10”
SPEAKER TYPE - SUBWOOFER
OHMS (PER COIL) - 2
NUMBER OF VOICE COILS - DUAL
CONE MATERIAL - TREATED PAPER
BASKET MATERIAL - CAST ALUMINIUM
MAGNET TYPE - FERRITE (CERAMIC)
SURROUND MATERIAL - TREATED FOAM
VOICE COIL DIAMETER - INCH (MM) - 2”
THIELE/SMALL PARAMETERS
SENSITIVTY (1W/1M): 83.9DB
VAS (L): 23.6
XMAX (MM): 7(MM)
POWER HANDLING RMS: 300W
POWER HANDLING MAX: 600W
MOUNTING DIAMETER : 9.47” (240.5MM)
Product Manuals

Feel the Boom!
Cerwin-Vega's top-notch subwoofers deliver unrivaled durability, power, and sound performance. Whether you're cruising down the highway or hitting the off-road trails, experience bass that moves you!
Bass You Can Trust!
Cerwin-Vega subwoofers fuse cutting-edge engineering with premium materials to deliver that deep, reliable bass you crave. Experience unbeatable performance and transform your ride's audio experience.
2 nd time buying. Not cause it broke. Cause I going with two instead of 2 8in subs
