4-Channel XED Series Full Range Class-D Amplifier - XED6004D

$189.99 USD
$189.99 USD
Sale Sold out
Channel: 4 Channel (600W)
  • Secure Checkout
  • 100% Authentic Products100% Authentic
  • Enjoy Free Shipping!Free Shipping
  • Live Chat SupportLive Support

4 Channel XED Series Full Range Class-D Amplifier

Upgrade your vehicle’s sound system with the Cerwin-Vega XED6004D XED Series 4-Channel Full Range Class-D Amplifier, a high-performance amplifier engineered to deliver powerful sound, exceptional efficiency, and long-lasting reliability. Built with Cerwin-Vega’s Xtreme Energy Design, this amplifier provides the perfect combination of performance, durability, and compact efficiency for modern car audio systems.

The XED6004D 4-channel amplifier is designed to power multiple speakers while maintaining clean, distortion-free sound across the entire frequency range. Whether you're driving component speakers, coaxial speakers, or bridging channels for increased power, this amplifier delivers the dynamic output and clarity needed to enhance your in-car listening experience.

Using advanced Class-D amplifier technology, the XED6004D maximizes power output while minimizing heat generation and electrical demand. This high-efficiency design ensures that the amplifier operates cooler and more efficiently than traditional amplifier designs, allowing for reliable performance during extended listening sessions or high-output audio setups.

The amplifier’s lightweight aluminum chassis serves as an effective heat sink, helping to dissipate heat and maintain stable operation even under demanding conditions. This rugged yet compact design makes the XED6004D ideal for installations where space is limited while still delivering the performance expected from Cerwin-Vega amplifiers.

Engineered with premium internal components and precision construction, the Cerwin-Vega XED Series amplifiers are built to withstand the demands of high-performance car audio systems. From powerful midrange output to crisp highs and tight bass response, the XED6004D provides the balanced sound reproduction needed for an immersive listening experience.

Key Features:
4-channel full range Class-D car audio amplifier
High-efficiency Class-D technology for powerful output
Lightweight aluminum chassis for superior heat dissipation
Clean, distortion-free sound performance
Flexible system configuration for speakers or bridged setups
Ideal for aftermarket car audio upgrades

The Cerwin-Vega XED6004D amplifier delivers the power, clarity, and efficiency needed to elevate your vehicle’s audio system—bringing Xtreme Energy and legendary Cerwin-Vega performance to every drive.

4-Channel Full Range Digital Amplifier

Power Rating (RMS)

FREQUENCY RESPONSE (HZ): 35HZ - 350HZ
RMS POWER PER CHANNEL 4Ω 80W X 4
RMS POWER PER CHANNEL 2Ω 120W X 4

Power Supply

  • Power Supply: Full WPM
  • Power Supply Threshold: 10.0V-16.0V (DC)
  • Idle Current: (0.7A)

Distortion

  • THD 4 (1KHZ @4Ω): 0.1%
  • S/N RATIO (A WEIGHTED @1W): -85dBA
  • S/N RATIO (A WEIGHTED @FP): -101.1dBA

Input Sensitivity

  • Low Level Input: 250mV-10.0V
  • High Level Input: 1.3V~>20.0V

Input Impedance

  • Low Level Input: 10KΩ
  • High Level Input: 100KΩ

Output Stage

  • Output Impedance: 2Ω
  • Damping Factor (50Hz@4Ω): >70
  • Bandwidth (-3db): 10Hz-3KHz

Crossover (1-12dB/Oct)

  • Variable High-Pass: 35Hz-250Hz
  • Variable low-Pass: 35Hz-250Hz

Fuse Rating

  • 2 x 25A (Inside)

Dimensions

  • Length x Width x Height: 7.1”x4.7”x1.8” (180mm x 120mm x 46.5 mm)

FEATURES

  • LED Power/Protect Light Indicator
  • Selectable X-Over: High Pass/Flat/Low Pass
  • 1-year Manufacturer's Warranty
  • MFR #: XED6004D

View Product Details

Xtreme Power, Ultimate Precision

The XED6004D 4-Channel Class-D Amplifier delivers high-efficiency power and clean sound. With advanced Class D technology and a lightweight aluminum chassis, it ensures reliable performance while driving subwoofers and speakers with ease.

Built for High-Performance Systems

Crafted with premium components and robust construction, the XED6004D handles demanding setups effortlessly. Experience deep bass, crisp highs, and seamless mids for an immersive car audio experience.

Q1: What are Cerwin-Vega XED Amplifiers designed for?
A: Cerwin-Vega XED Amplifiers are designed for everyday car audio upgrades, providing efficient and reliable power for speakers, subwoofers, and custom audio systems. They are a great choice for improving factory systems or building a new setup.

Q2: What is the difference between mono, 2-channel, 4-channel, and 5-channel XED Amplifiers?
A:
Mono amplifiers are designed primarily for powering subwoofers and enhancing low-frequency performance.
2-channel amplifiers are ideal for powering a pair of speakers or smaller audio upgrades.
4-channel amplifiers provide flexible power for front and rear speaker systems.
5-channel amplifiers combine multiple full-range channels with a dedicated subwoofer channel for a complete audio solution.

Q3: Why choose a Class-D amplifier for my vehicle audio system?
A: Class-D amplifiers provide high efficiency, compact designs, and reliable power output, helping deliver strong performance while reducing heat and power consumption compared with traditional amplifier designs.

Q4: How do I choose the right XED Amplifier for my system?
A: Choose based on your speaker or subwoofer power requirements, RMS ratings, impedance, number of channels, and overall system goals. Matching the amplifier specifications with your components ensures better performance and system reliability.

Q5: Can XED Amplifiers be used for factory audio upgrades?
A: Yes. XED Amplifiers are suitable for OEM system improvements, speaker upgrades, subwoofer installations, and custom car audio builds. Select the amplifier configuration that matches your desired system setup.
