XED Series 4-Channel Full Range Class-D Amplifier - XED4004D

$169.99 USD
$169.99 USD
Sale Sold out

Weight: 3.4 lb

Size: 4 Channel (400W)

XED4004D - XED Series 4-Channel Full Range Class-D Amplifier

Upgrade your vehicle’s audio system with the Cerwin-Vega XED4004D XED Series 4-Channel Full Range Class-D Amplifier, a compact yet powerful amplifier designed to deliver clean sound, efficient performance, and the legendary Cerwin-Vega energy that car audio enthusiasts expect. Built with Cerwin-Vega’s Xtreme Energy Design, this amplifier provides the power and clarity needed to transform your driving experience into an immersive sound adventure.

The XED4004D 4-channel amplifier is engineered to power front and rear speakers with impressive clarity and dynamic range. Whether you're running component speakers, coaxial speakers, or bridging channels for additional power, this amplifier provides flexible system configuration and dependable output for a wide range of car audio setups.

Utilizing advanced Class-D amplifier technology, the XED4004D delivers high-efficiency power with minimal heat generation. This modern amplifier design maximizes output while reducing electrical strain and energy consumption, allowing your audio system to perform at higher levels without overheating or distortion.

The amplifier’s lightweight aluminum chassis not only gives it a sleek, durable design but also acts as a heat-dissipating structure that helps maintain optimal operating temperatures. This efficient thermal management ensures reliable performance during extended listening sessions or high-output audio playback.

Engineered with precision and built using quality internal components, the Cerwin-Vega XED Series amplifiers are designed to handle demanding audio systems while maintaining consistent performance. From detailed midrange frequencies to crisp highs and tight bass response, the XED4004D ensures your music is reproduced with clarity and power.

Key Features:
4-channel full range Class-D car audio amplifier
High-efficiency digital amplifier technology for strong output
Compact aluminum chassis for effective heat dissipation
Flexible system configuration for speakers or bridged setups
Clean, distortion-free sound performance
Ideal for aftermarket car audio upgrades

The Cerwin-Vega XED4004D amplifier delivers powerful performance, energy-efficient operation, and the bold sound signature that makes Cerwin-Vega a leader in high-performance car audio.

4-Channel Full Range Digital Amplifier

Power Rating (RMS)

FREQUENCY RESPONSE (HZ): 35HZ - 350HZ
RMS POWER PER CHANNEL 4Ω 60W X 4
RMS POWER PER CHANNEL 2Ω 90W X 4

Power Supply

  • Power Supply: Full WPM
  • Power Supply Threshold: 10.0V-16.0V (DC)
  • Idle Current: (0.7A)

Distortion

  • THD 4 (1KHZ @4Ω): 0.1%
  • S/N RATIO (A WEIGHTED @1W): -85dBA
  • S/N RATIO (A WEIGHTED @FP): -101.1dBA

Input Sensitivity

  • Low Level Input: 250mV-10.0V
  • High Level Input: 1.3V~>20.0V

Input Impedance

  • Low Level Input: 10KΩ
  • High Level Input: 100KΩ

Output Stage

  • Output Impedance: 2Ω
  • Damping Factor (50Hz@4Ω): >70
  • Bandwidth (-3db): 10Hz-30KHz

Crossover (1-12dB/Oct)

  • Variable High-Pass: 35Hz-250Hz
  • Variable low-Pass: 35Hz-250Hz

Fuse Rating (Inside)

  • 30A

Dimensions

  • Length x Width x Height: 6.3”x4.7”x1.8” (160mm x 120mm x 46.5 mm)

FEATURES

  • LED Power/Protect Light Indicator
  • Selectable X-Over: High Pass/Flat/Low Pass
  • 1-year Manufacturer's Warranty
  • MFR #: XED4004D

View Product Details

Xtreme Power, Ultimate Precision

The XED4004D 4-Channel Class-D Amplifier delivers high-efficiency power and clean sound. With advanced Class D technology and a lightweight aluminum chassis, it ensures reliable performance while driving subwoofers and speakers with ease.

Built for High-Performance Systems

Crafted with premium components and robust construction, the XED4004D handles demanding setups effortlessly. Experience deep bass, crisp highs, and seamless mids for an immersive car audio experience.
